| 发射频率范围 （TX Frequency range)： |
1.6–2.9999 MHz 4.0–4.9999 MHz 6.0–6.9999 MHz 8.0–8.9000 MHz 12.0–13.9999 MHz 16.0–17.9999 MHz 18.0–19.9999 MHz 22.0–22.9999 MHz 25.0–27.5000 MHz |
| 接收频率范围（RFrequency range): |
0.5–29.9999 MHz |
| 供电电压范围（Power supply requirement): |
13.6V DC ±15% (negative ground) |
| 发射功率(RF output power (PEP): |
150/60/20W (below 24MHz) 60/20W (above 24MHz) |
| 外观尺寸Dimensions (W×H×D) (Projections not included) |
291.4×116.4×315 mm 11.47×4.58×12.4 in |
| 发射类型（Type of emission）： |
J3E, J2B, R3E, A1A (12dB SINAD) |
| 是否有DSC功能 |
否 |
| DSC 等级 |
无DSC |
